Hepatic adenoma: indications for minimally invasive resection
Introduction
Hepatic adenoma (HA), also known as hepatocellular adenoma, is a benign tumor of the epithelial cells of the liver. Although it is benign, HA has a risk of malignant transformation as well as hemorrhagic complications (1). It is relatively uncommon with the incidence being 1/1,000,000 and it affects more women than men with a ratio of approximately 10:1. HA is usually hormonally-induced and therefore strongly associated with the use of oral contraceptive pills in female patients and anabolic steroids in males. Recent evidences have associated HA with obesity and metabolic syndrome (2,3).
During the last 15 years, laparoscopic liver surgery has had a wide diffusion thanks to the standardization of the technique and its reported benefits (4,5). As compared to open liver resection, laparoscopic liver surgery has been associated with lower blood loss, shorter hospital-stay, and faster postoperative recovery (4). To date, the laparoscopic approach is standard for small lesions (<5 cm) in the antero-lateral segments, while it is still under evaluation for major hepatectomies and resection of postero-superior segments (6,7). Nevertheless, the scenario is rapidly evolving and HPB referral centers perform 15% to 30% of liver resections using a minimally invasive approach (8-10). This can reach 50–80% in some centers (8,11).
Patients with benign tumors of the liver are the ideal candidates for laparoscopic surgery for different reasons: firstly, they do not need a safety resection margin or any lymph-node dissection; secondly, benign diseases are often diagnosed in young people who are mainly concerned about cosmetic results. Nevertheless, not all the HA should be removed as only some of them are at risk for complications (hemorrhage/malignant transformation). The present review aims to analyze the indications and the results of a laparoscopic resection in patients with HA.
Methods
A systematic search of PubMed, Science Citation Index, and Embase databases was performed for articles published before May 2019 relevant to laparoscopic resection of hepatic adenoma. English language articles were selected using the keywords ‘hepatic adenoma’, ‘hepatocellular adenoma’, ‘hepatic benign tumor’, ‘laparoscopic hepatectomy’, ‘laparoscopic liver surgery’, and ‘laparoscopic liver resection’ to identify all reports that may pertain to the review issue. Manual cross-referencing was performed, and relevant references from selected papers were reviewed. Case reports were excluded.
Results
After the literature review, 7 manuscripts, specifically focused on HA and their minimally invasive resection, were identified (12-18). Additional data have been extracted from a review about HA management (19) or from papers about benign solid tumors and laparoscopic liver resection that also considered some HA (20-26).
Which adenoma should be resected?
HA is usually asymptomatic and is discovered incidentally on routine imaging such as ultrasonography in most patients (1). Patients with a diagnosis of HA should be accurately evaluated to exclude any sign of current malignant disease, namely hepatocellular carcinoma, and to elucidate the risk of later bleeding and of malignant transformation. Several classifications of HA have been proposed to accomplish this aim and, consequently, to identify patients that should undergo liver surgery. The latest one has been proposed by Nault et al. on the basis of an extended molecular analysis of more than 500 HA (27). Six different types of HA were identified: HNF1A inactivated HA, Inflammatory HA, β-catenin mutated HA exon 3, β-catenin mutated HA exon 7/8, sonic hedgehog HA and unclassified HA. β-catenin mutated HA exon 3 has been associated with a high risk of malignant transformation, while sonic hedgehog HA has been associated with a high risk of bleeding. How can this molecular classification be translated into clinical practice? HNF1A inactivated HA can be diagnosed by magnetic resonance imaging, while, in the remaining cases, a liver biopsy could identify mutations at risk for complications (3). However, this is not yet the standard and clinical data still drive current practice. First, the risk of malignant transformation is persistently high in all HA in male patients. Second, large HA size (>5 cm) is associated with an increased risk for both malignancy and bleeding. Accordingly, EASL proposed a very practical and easy-to-apply flowchart for HA management (1). Three main parameters determine treatment, i.e., sex, HA size, and β-catenin mutation. Liver resection is recommended in all male patients, irrespective of the HA size. In women, the first step is lifestyle change and re-evaluation after 6 months. If the HA increases in size or is stable and >5 cm, resection is indicated. If not (HA regression or stable and <5 cm), follow-up is adequate. Liver biopsy is not recommended, but if it is performed and identifies a β-catenin mutated HA, especially if exon 3 is mutated, surgery should be considered, independently of the HA size. Finally, liver resection is indicated in symptomatic patients or in patients with non-conclusive diagnosis of benign disease and suspicion of malignant tumor.
An additional clinical scenario should be considered, i.e., a liver adenomatosis (>10 HA). The term adenomatosis has now been replaced by “multiple HA”. Management of such patients is complex: an adequate follow-up of all tumors can be difficult to perform and the resection of all HA can require complex procedures that carry significant risks or can even be impossible to perform. Some patients with multiple HA have been scheduled for transplantation. Present EASL guidelines recommend a more cautious stepwise approach: (I) resection of HA >5 cm, (II) resection of any lesion suspected of malignant transformation and (III) follow-up of the remaining lesions (1).
Which hepatic adenoma can be resected by laparoscopy?
The first laparoscopic left lateral sectionectomy, that was also the first anatomic hepatectomy performed by laparoscopy, has been reported in 1996 by Azagra et al. for a symptomatic HA (28). During the last decade, the proportion of HA undergoing laparoscopic resection has progressively increased (13-15,17,18), as the proportion of all liver tumors also increased (4). The most recent series reported a laparoscopic approach in about 40–50% of resections for HA (17,18). The large tumor size (>5 cm in most patients) probably limited a further diffusion. It is not possible to identify specific indications for minimally invasive liver surgery for HA because very few papers have focused on this topic. The available series mostly included patients with single tumors and HA having a median size that ranges from 50 to 85 mm. Most procedures were minor hepatectomies, even if some major liver resections have been reported in the more recent series. Interestingly, some authors highlighted the possibility of using a laparoscopic approach even in patients with so-called “hemorrhagic HA”, i.e., HA having had a hemorrhagic complication in their history (18).
The indications of a minimally invasive approach for HA mainly rely on technical considerations. A laparoscopic approach is standard for limited resections of antero-lateral segments and left lateral sectionectomy, especially in the presence of small tumors (6,7). HA requiring such resections should be routinely considered for a laparoscopic resection, even if their size (usually >5 cm) could be a limitation. Limited resections of postero-superior segments (segments 7, 8 and 4 s) and segment 1 are more difficult to perform, as are major hepatectomies. However, high-volume centers reported feasibility and safety of such complex procedures with excellent outcomes (29-31).
The type of resection is not per se sufficient to predict the difficulty of laparoscopic liver surgery. Additional data should be considered, such as the tumor size and its proximity to major intrahepatic vessels (32). Those parameters together with the scheduled resection have been included in the Ban et al. score (32). The authors identified three different classes of laparoscopic liver resections that require progressively increasing surgical expertise. The most complex procedures are the less standardized ones and, if performed by non-adequately trained surgeons, are at risk for intraoperative problems, namely bleedings and postoperative severe complications. Halls et al. demonstrated that an emergency conversion of laparoscopic liver resection because of an unfavorable intraoperative event is associated with poor outcomes, even with non-negligible mortality risk (33). Every surgeon should be aware of his/her proper expertise and of the skills of the entire team (surgeons, anesthesiologists, and nurses). Adequate training in both laparoscopic and liver surgery is mandatory to approach any laparoscopic liver resection (7,34) and the learning curve should be completed before facing the most complex procedures (35). These rules must be respected even if HA is a benign disease mainly of young patients.
Does a laparoscopic approach modify indications?
Many patients with HA do not need a liver resection and should be scheduled for a simple follow-up by annual imaging (1). However, lifelong follow-up is quite demanding, especially considering that HA is often diagnosed in young people, who may have low compliance to follow-up protocols in the long term. The laparoscopic approach achieved excellent safety and outcome, including cosmetic outcomes, with a very quick return to normal life (4). Those results led some authors to propose an upfront resection of all easy-to-remove HA to prevent costs and discomfort of follow-up, and to prevent any future risk (36). In the literature, it is evident that surgeons adopted widened indications to resection in patients with benign tumors suitable for laparoscopic surgery. Benign tumors are a rare indication to surgery in HPB centers, but they represent a consistent part of laparoscopic hepatectomies. Ciria et al. reviewed approximately 9,000 laparoscopic liver resections published before July 2014: more than one-third of procedures were performed for benign tumors (4). In the I Go MILS (Italian Group of Minimally Invasive Liver Surgery) prospective registry, 1,678 minimally invasive liver resections have been performed between 2014 and 2017 of which 22% were for benign tumors (8). Toro et al. reviewed all the manuscripts reporting resections of benign liver tumors between 1971 and 2010. Even if the whole number of resections for HA (open and laparoscopic) progressively decreased, the number of laparoscopic resections constantly increased (25). These data most likely reflect an inappropriate widening of surgical indications justified by the minimally invasive approach.
The first consensus conference about laparoscopic liver surgery held in Lousville in 2009 immediately addressed this point (34). The scientific committee had to answer the following question: “Should indications for resection of asymptomatic benign hepatic lesions be widened?”. The experts clearly stated that the possibility to perform a laparoscopic resection should not modify the indications to resect a benign tumor. Hypothetical benefits from HA resection do not outweigh the actual surgical risks when we are out of standard indications.
Results of minimally invasive surgery for hepatocellular adenoma
Very few analyses specifically considered laparoscopic resection of HA. Little additional data can be extrapolated from large series of laparoscopic liver resection of benign tumors that included some HA, but rarely reported specific data. Table 1 summarizes the largest available series. About 600 laparoscopic liver resections for HA have been analyzed, the two largest series collecting two-third of patients through multicenter analyses and only 7 series reporting more than 10 patients. Conversion rates range from 0 to 18%. Operative time was short and blood loss was low in all series.
Table 1
First author | Year | # | Tumor size, mm* | Major hepatectomy | Conversion | Operative time, min* | Blood loss, mL* | Blood transfusion | Mortality | Overall morbidity | Severe morbidity± | Hospital stay, days* |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Katkhouda ( |
1999 | 9 | NA | 0 | 1 [11%] | NA | NA | NA | 0 | 0 | 0 | NA |
Descottes ( |
2003 | 17 | NA | 0 | 1 [6%] | NA | NA | 1 [6%] | 0 | 2 [12%] | 0 | NA |
Ardito ( |
2007 | 7 | NA | NA | 1 [14%] | NA | NA | NA | 0 | NA | NA | NA |
Cho ( |
2008 | 9 (4 hand-assisted) | NA | 1 [11%] | 0 | NA | 69 [0–150] | 0 | 0 | 0 | 0 | 3 [1–7] |
Troisi ( |
2008 | 11 | NA | NA | 2 [18%] | NA | NA | NA | NA | NA | NA | NA |
Abu Hilal ( |
2011 | 15 | 85 [25–180] | NA | 0 | 270 [135–360] | 500 [100–2,000] | 1 [7%] | 0 | 1 [7%] | 1 [7%] | 4 [1–18] |
Herman ( |
2012 | 31 | 75 [30–140] | 3 [10%] | 0 | NA | NA | 0 | 0 | 1 [3%] | 1 [3%] | 3.8 [1–15] |
de'Angelis ( |
2014 | 36 | 50.5 [25–130] | 9 [25%] | 3 [8%] | 165 [90–390] | 200 [50–1,600] | 0 | 0 | 3 [8%] | 3 [8%] | 7.5 [3–26] |
Bieze ( |
2014 | 5 | 84 [60–110] | 0 | 0 | 100 [69–144] | NA | NA | 0 | 3 [60%] | 0 | 5 [2–7] |
Laurent ( |
2016 | 26 Hemorrhagic | NA | NA | NA | NA | NA | 0 | 0 | 10 [38%] | 3 [12%] | 5 [2–10] |
182 Non–hemorrhagic | NA | 13 [7%] | NA | 132 [83–510] | 130 [50–560] | NA | 0 | 41 [23%] | 7 [4%] | 4 [2–6] | ||
Landi ( |
2017 | 208 | 60 [40–82] | 20 [10%] | 13[6%] | 149 [113–230] | 93 [50–271] | 8 [RBC units] | 0 | 50 [24%] | 10 [5%] | 5 [4–7] |
*Values are expressed as median [range] except for Herman
Mortality was nil. Severe morbidity ranges from 0 to 12%, the highest values being observed in patients with hemorrhagic HA (18). The largest series consistently reported an overall morbidity rate of 22–24% and a severe morbidity rate of 5%. Transfusion rates were nil in most series, and 4% in the multicenter series by Landi et al. (17). The hospital stay was short (median 5 days).
Five studies compared the outcome of open and laparoscopic resections for HA (13-15,17,18). All were retrospective analyses. Only one study used a propensity score analysis to match open and laparoscopic patients (17). In the analysis of Biezel et al., the laparoscopic group had shorter operative time (100 vs. 170 min in the open group) and shorter hospital stay (5 vs. 7 days) (13). Cho et al. reported the following advantages in the laparoscopic group: shorter hospital stay (3 vs. 7 days in the open group), lower blood loss (69 vs. 305 mL), and lower RBC units transfused (0 vs. 2.5) (14). de'Angelis et al. did not show any significant difference between groups, except for a lower rate of pedicle clamping in the laparoscopic group (28% vs. 58% in the open group) (15). The study by Laurent et al. distinguished hemorrhagic and non-hemorrhagic HA (18). In both types of HA, the laparoscopic group had lower bleeding (hemorrhagic HA: transfusion rate 0 vs. 16% in the open group; non-hemorrhagic HA: blood loss 130 vs. 310 mL, respectively) and shorter hospital stay (5 vs. 8 days; 4 vs. 7 days, respectively). In non-hemorrhagic HA, the laparoscopic group had lower overall and severe postoperative morbidity rates (23% vs. 47% in the open group; and 4% vs. 11%, respectively), while, in hemorrhagic HA, the two groups had similar complications rate. Finally, Landi et al., who adopted a propensity score matching, reported similar operative time, overall morbidity rate, and severe morbidity rate in laparoscopic and open group, but observed lower blood loss (93 vs. 196 mL), lower transfusion rate (8 vs. 24 RBC units transfused), and shorter hospital stay (5 vs. 7 days) in the laparoscopic group (17).
Some final considerations
HA is a rare benign disease. Only selected patients require a liver resection: male patients; female patients with progressively enlarging nodule or HA >5 cm or a β-catenin mutated tumor (especially if β-catenin mutated HA exon 3); symptomatic patients. The number of minimally invasive resections performed for HA reported in the literature has progressively increased in the most recent years. Laparoscopic resection of HA is safe and feasible and carries the same advantages of minimally invasive liver surgery for other diseases. The minimally invasive approach is standard for HA requiring limited resections of antero-lateral segments or left lateral sectionectomy. Laparoscopic complex resections for HA have been reported, but they are still under evaluation and should be reserved for high-volume centers with adequate expertise. A three-step decisional process should be respected. The surgeon should evaluate: firstly, if the patient needs surgery; secondly, which resection is appropriate; thirdly, if a laparoscopic approach is suitable in his/her center. The possibility of performing a laparoscopic resection for HA should not widen indications or modify surgical strategy. Furthermore, the surgeon’s awareness of his/her expertise and learning curve and that of the entire teams’ capabilities is paramount to increase patient safety and optimize outcomes.
Acknowledgments
Funding: None.
Footnote
Provenance and Peer Review: This article was commissioned by the Guest Editor (Francesco Ardito) for the series “The Role of Minimally Invasive Liver Surgery to Treat Hepatic Benign Disease” published in Laparoscopic Surgery. The article has undergone external peer review.
Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/ls.2019.08.03). The series “The Role of Minimally Invasive Liver Surgery to Treat Hepatic Benign Disease” was commissioned by the editorial office without any funding or sponsorship. The authors have no other conflicts of interest to declare.
Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.
Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
References
- European Association for the Study of the Liver (EASL). EASL Clinical Practice Guidelines on the management of benign liver tumours. J Hepatol 2016;65:386-98. [Crossref] [PubMed]
- Bioulac-Sage P, Taouji S, Possenti L, et al. Hepatocellular adenoma subtypes: the impact of overweight and obesity. Liver Int 2012;32:1217-21. [Crossref] [PubMed]
- Nault JC, Paradis V, Cherqui D, et al. Molecular classification of hepatocellular adenoma in clinical practice. J Hepatol 2017;67:1074-83. [Crossref] [PubMed]
- Ciria R, Cherqui D, Geller DA, et al. Comparative Short-term Benefits of Laparoscopic Liver Resection: 9000 Cases and Climbing. Ann Surg 2016;263:761-77. [Crossref] [PubMed]
- Viganò L, Tayar C, Laurent A, et al. Laparoscopic liver resection: a systematic review. J Hepatobiliary Pancreat Surg 2009;16:410-21. [Crossref] [PubMed]
- Abu Hilal M, Aldrighetti L, Dagher I, et al. The Southampton Consensus Guidelines for Laparoscopic Liver Surgery: From Indication to Implementation. Ann Surg 2018;268:11-8. [Crossref] [PubMed]
- Wakabayashi G, Cherqui D, Geller DA, et al. Recommendations for laparoscopic liver resection: a report from the second international consensus conference held in Morioka. Ann Surg 2015;261:619-29. [PubMed]
- Aldrighetti L, Ratti F, Cillo U, et al. Diffusion, outcomes and implementation of minimally invasive liver surgery: a snapshot from the I Go MILS (Italian Group of Minimally Invasive Liver Surgery) Registry. Updates Surg 2017;69:271-83. [Crossref] [PubMed]
- Stoot JH, Wong-Lun-Hing EM, Limantoro I, et al. Laparoscopic liver resection in the Netherlands: how far are we? Dig Surg 2012;29:70-8. [Crossref] [PubMed]
- Takahashi Y, Katagiri S, Ariizumi SI, et al. Laparoscopic Hepatectomy: Current State in Japan Based on the 4th Nationwide Questionnaire. Gastroenterol Res Pract 2017;2017:6868745 [Crossref] [PubMed]
- Tomassini F, Scuderi V, Berardi G, et al. The practice of laparoscopic liver surgery in Belgium: a national survey. Acta Chir Belg 2017;117:15-20. [Crossref] [PubMed]
- Abu Hilal M, Di Fabio F, Wiltshire RD, et al. Laparoscopic liver resection for hepatocellular adenoma. World J Gastrointest Surg 2011;3:101-5. [Crossref] [PubMed]
- Bieze M, Busch OR, Tanis PJ, et al. Outcomes of liver resection in hepatocellular adenoma and focal nodular hyperplasia. HPB (Oxford) 2014;16:140-9. [Crossref] [PubMed]
- Cho SW, Marsh JW, Steel J, et al. Surgical management of hepatocellular adenoma: take it or leave it? Ann Surg Oncol 2008;15:2795-803. [Crossref] [PubMed]
- de'Angelis N, Memeo R, Calderaro J, et al. Open and laparoscopic resection of hepatocellular adenoma: trends over 23 years at a specialist hepatobiliary unit. HPB (Oxford) 2014;16:783-8. [Crossref] [PubMed]
- Herman P, Coelho FF, Perini MV, et al. Hepatocellular adenoma: an excellent indication for laparoscopic liver resection. HPB (Oxford) 2012;14:390-5. [Crossref] [PubMed]
- Landi F, De'Angelis N, Scatton O, et al. Short-term outcomes of laparoscopic vs. open liver resection for hepatocellular adenoma: a multicenter propensity score adjustment analysis by the AFC-HCA-2013 study group. Surg Endosc 2017;31:4136-44. [Crossref] [PubMed]
- Laurent A, Dokmak S, Nault JC, et al. European experience of 573 liver resections for hepatocellular adenoma: a cross-sectional study by the AFC-HCA-2013 study group. HPB (Oxford) 2016;18:748-55. [Crossref] [PubMed]
- Tsilimigras DI, Rahnemai-Azar AA, Ntanasis-Stathopoulos I, et al. Current Approaches in the Management of Hepatic Adenomas. J Gastrointest Surg 2019;23:199-209. [Crossref] [PubMed]
- Abu Hilal M, Di Fabio F, Teng MJ, et al. Surgical management of benign and indeterminate hepatic lesions in the era of laparoscopic liver surgery. Dig Surg 2011;28:232-6. [Crossref] [PubMed]
- Ardito F, Tayar C, Laurent A, et al. Laparoscopic liver resection for benign disease. Arch Surg 2007;142:1188-93. [Crossref] [PubMed]
- Descottes B, Glineur D, Lachachi F, et al. Laparoscopic liver resection of benign liver tumors. Surg Endosc 2003;17:23-30. [Crossref] [PubMed]
- Gigot JF, Hubert C, Banice R, et al. Laparoscopic management of benign liver diseases: where are we? HPB (Oxford) 2004;6:197-212. [Crossref] [PubMed]
- Katkhouda N, Hurwitz M, Gugenheim J, et al. Laparoscopic management of benign solid and cystic lesions of the liver. Ann Surg 1999;229:460-6. [Crossref] [PubMed]
- Toro A, Gagner M, Di Carlo I. Has laparoscopy increased surgical indications for benign tumors of the liver? Langenbecks Arch Surg 2013;398:195-210. [Crossref] [PubMed]
- Troisi R, Montalti R, Smeets P, et al. The value of laparoscopic liver surgery for solid benign hepatic tumors. Surg Endosc 2008;22:38-44. [Crossref] [PubMed]
- Nault JC, Couchy G, Balabaud C, et al. Molecular Classification of Hepatocellular Adenoma Associates With Risk Factors, Bleeding, and Malignant Transformation. Gastroenterology 2017;152:880-94.e6. [Crossref] [PubMed]
- Azagra JS, Goergen M, Gilbart E, et al. Laparoscopic anatomical (hepatic) left lateral segmentectomy-technical aspects. Surg Endosc 1996;10:758-61. [Crossref] [PubMed]
- Ishizawa T, Gumbs AA, Kokudo N, et al. Laparoscopic segmentectomy of the liver: from segment I to VIII. Ann Surg 2012;256:959-64. [Crossref] [PubMed]
- Kasai M, Cipriani F, Gayet B, et al. Laparoscopic versus open major hepatectomy: a systematic review and meta-analysis of individual patient data. Surgery 2018;163:985-95. [Crossref] [PubMed]
- Levi Sandri GB, Ettorre GM, Aldrighetti L, et al. Laparoscopic liver resection of hepatocellular carcinoma located in unfavorable segments: a propensity score-matched analysis from the I Go MILS (Italian Group of Minimally Invasive Liver Surgery) Registry. Surg Endosc 2019;33:1451-8. [Crossref] [PubMed]
- Ban D, Tanabe M, Ito H, et al. A novel difficulty scoring system for laparoscopic liver resection. J Hepatobiliary Pancreat Sci 2014;21:745-53. [Crossref] [PubMed]
- Halls MC, Cipriani F, Berardi G, et al. Conversion for Unfavorable Intraoperative Events Results in Significantly Worse Outcomes During Laparoscopic Liver Resection: Lessons Learned From a Multicenter Review of 2861 Cases. Ann Surg 2018;268:1051-7. [Crossref] [PubMed]
- Buell JF, Cherqui D, Geller DA, et al. The international position on laparoscopic liver surgery: The Louisville Statement, 2008. Ann Surg 2009;250:825-30. [Crossref] [PubMed]
- Vigano L, Laurent A, Tayar C, et al. The learning curve in laparoscopic liver resection: improved feasibility and reproducibility. Ann Surg 2009;250:772-82. [Crossref] [PubMed]
- Koffron A, Geller D, Gamblin TC, et al. Laparoscopic liver surgery: Shifting the management of liver tumors. Hepatology 2006;44:1694-700. [Crossref] [PubMed]
